How to Prepare Your PCB for DO-160 EMC Testing
Most PCB failures in DO-160 section 21 testing are preventable. Here's what our engineers check before a board goes near a test chamber.
Bulwark Engineering TeamRead →
// DFM · Production
5 DFM Mistakes That Double Your Production Cost
Design for Manufacturing isn't just about what works — it's about what's economically viable at scale. Here are the most expensive mistakes we see from R&D teams.
Bulwark Engineering TeamComing Soon
// MIL-STD-810 · Thermal
Thermal Design for MIL-STD-810 Temperature Cycling
Operating from -55°C to +125°C is not just a spec — it's a completely different approach to component selection, PCB design, and mechanical enclosure engineering.
By Bulwark Engineering Team · Defense & Avionics Electronics
We've seen it happen dozens of times. A board that works perfectly in the lab — clean signals, solid performance, happy engineers — walks into a DO-160 test chamber and fails Section 21 emissions by 15 dB. The system gets shipped back. The program slips three months. The certification costs double.
It's not a design flaw in the traditional sense. The board does what it's supposed to do electronically. The failure is a system integration problem, and it usually shows up in three places: the PCB layout, the enclosure, and the cables. Here's how we approach it.
01 — Know What You're Actually Testing
The Relevant DO-160 Sections
Before touching a trace or ordering a gasket, identify which sections your equipment is subject to. The three that cause the most pain in practice:
§20
RF Susceptibility
Radiated and conducted. Tests whether your system behaves correctly when external RF is present — from airport radars to VHF comms. Category M covers most avionics equipment. Category H is for equipment near transmitters.
§21
RF Emissions
What your system radiates and conducts back into the aircraft power bus. This is where switching regulators, clock lines, and unfiltered I/O create the most problems. Limits are defined per category — M, H, L — in terms of field strength (dBμV/m) and conducted voltage (dBμV).
§25
Electrostatic Discharge
8 kV contact, 15 kV air discharge on accessible surfaces. Failures here are often enclosure bonding issues, not component-level protection. A good TVS diode doesn't help if the ESD pulse bypasses your board entirely through an unbonded panel seam.
FIELD NOTE
Category letters (A through Z in some sections) define the severity of the environment — not just the test level. Check RTCA/DO-160G Table 20-1 and Table 21-1 carefully. Selecting the wrong category is a common early mistake that affects the entire test plan.
02 — Where Emissions Come From
Control the Source, Not the Symptom
Most Section 21 failures trace back to one of three sources: the switching power supply, high-speed digital lines, or return current paths that nobody drew on the schematic — because return current never shows up on schematics.
The switching regulator is the worst offender in almost every system we've worked on. A typical 400kHz buck converter generates harmonic energy well into the hundreds of MHz range. The question isn't whether it radiates — it does — it's whether you've given that energy a controlled path back to its source before it finds an antenna (which in this context is usually a cable).
Loop Area Minimization
Every high-current, high-frequency path forms a magnetic dipole antenna proportional to its loop area. Keep the switching node, inductor, and output capacitor physically tight. The return current path on your ground plane matters as much as the signal path — route them deliberately, not by default.
Ground Plane Integrity
Solid, uninterrupted ground planes on inner layers are non-negotiable. Slot cuts, via-heavy zones, and connector placement that interrupts the plane all force return currents to detour — and every detour is a radiated emission waiting to happen. Simulate current density if your tools allow it.
Filtering — at the Right Place
LC filters and ferrite beads work, but placement is everything. A ferrite bead on a power line is useless if it's placed after the decoupling capacitor, or if the capacitor's via parasitic defeats it above 50 MHz. Place filtering at the point of entry — enclosure wall, connector pin — not somewhere convenient on the board.
03 — The Enclosure Is Part of Your EMC Design
Shielding Done Right
A well-designed PCB inside a poorly bonded enclosure will still fail. We've measured 20–30 dB of additional attenuation available from a properly gasketed aluminum enclosure versus one with floating panel seams. That's the difference between passing and failing at margin.
▸
Enclosure material: Aluminum is the standard. Plated polymer housings work for lighter-weight applications but require careful surface preparation at bonding points. Avoid painted surfaces under gaskets — the anodizing or paint breaks the electrical bond.
▸
Seam impedance: Target <2.5 mΩ bond impedance at every seam. Use EMI gaskets — compressed finger strip or conductive foam — at all panel joints. Test with a milliohm meter, not a continuity beeper.
▸
Apertures: Every hole in an enclosure — display cutout, ventilation slot, connector opening — is a potential leakage point. The rule of thumb: a slot radiates significantly at wavelengths 10× the slot length. A 30mm slot is an antenna at 1 GHz. Honeycomb ventilation panels maintain airflow while limiting aperture dimensions.
▸
PCB-to-chassis bonding: The PCB ground must have a direct, low-impedance path to chassis ground. Standoffs with proper contact, not floating. If your design uses signal ground separate from chassis ground, the bond point and its impedance must be defined — not left to the assembler.
04 — Cables Are Antennas Until Proven Otherwise
Cable and Connector Management
In practice, cables are the primary EMI radiator in most airborne systems. A 1-meter unshielded cable at 100 MHz is a reasonably efficient antenna. If your switching noise has any path to reach that cable — and it usually does — it will radiate.
Shield Termination
360° termination at the connector backshell, not a pigtail. A 25mm pigtail ground connection defeats the shielding above about 10 MHz. Use backshell clamps that make direct contact around the full cable circumference. Both-end grounding is standard for most avionics applications — floating one end is only appropriate for very specific low-frequency audio situations.
Feedthrough Filters
Any signal or power line exiting the enclosure is a potential emission path. Feedthrough capacitors (mounted at the enclosure wall, not the PCB) give you a clean path to chassis ground at the exact point of penetration. They're bulky and add cost — but they work, and they're often the only viable fix when the PCB can't be redesigned.
05 — Thermal Design Has EMC Consequences
Heat Affects More Than Temperature
This connection is underappreciated. As junction temperatures rise, oscillator drift increases, switching rise times change, and capacitor ESR increases — all of which affect the spectral content of your emissions. A design that barely passes at room temperature may fail at 70°C because the switching noise floor shifts.
More directly: thermal interface materials (TIMs) between the PCB and chassis create a conductive path that affects both heat flow and the impedance of the PCB-to-chassis bond. Silicone-based TIMs are generally non-conductive electrically. If your thermal design relies on the TIM for the PCB ground bond, that's a problem.
PRACTICAL POINT
Run your pre-compliance tests at operating temperature, not room temperature. The lab environment is controlled — real aircraft compartments are not. We've seen units pass pre-compliance at 25°C and fail formal testing at 55°C soak, with the emissions rising 8–12 dB. Test the worst case before you pay for the formal test.
06 — Before the Lab
Pre-Compliance Testing Is Not Optional
A formal DO-160 EMC test at an accredited lab costs real money — typically $15,000–40,000 depending on sections, category, and equipment complexity. Showing up without pre-compliance data is a gamble that rarely pays off.
You don't need a full shielded room for pre-compliance. Near-field probes with a spectrum analyzer will find most emission problems. Ferrite clamps on suspect cables. A basic conducted emissions scan on the power input. You won't get calibrated absolute levels — but you'll find the dominant noise sources, which is what matters at this stage.
What to Look For
Switching frequency fundamentals and their harmonics. Clock harmonics from processors and FPGAs. Any signal that shows up consistently on near-field probes near cables or connector areas — that's your most likely radiated emission candidate.
What Pre-Compliance Won't Catch
Susceptibility issues are much harder to pre-test without proper RF generation equipment. For Section 20, rely on simulation, literature data for your components, and shielding calculations. ESD (Section 25) can be roughly assessed with a basic ESD gun — just don't mistake the absence of obvious failures for a guarantee of compliance.
Conclusion
EMC Is a System Problem
The most important shift in thinking: DO-160 EMC compliance is not a PCB problem. It's a system integration problem. The PCB layout matters, but so does the enclosure, the cable harness, the connector backshells, and the way the chassis is bonded to aircraft structure.
We've successfully qualified PCBs for airborne use that were not significantly redesigned — the pass came from enclosure improvements, proper cable shielding, and feedthrough filtering at the enclosure wall. Redesign isn't always the answer. Understanding where the energy is coming from, where it's going, and why it's finding a path — that's the answer.
If you're approaching a DO-160 qualification and have questions about your specific system, our team does pre-assessment reviews before formal test planning. The earlier you identify integration risks, the cheaper they are to fix.
